Description
Summary
OasisFly35 – Max compatible with O4 Pro HD VTX. DC frame + 1804 motors deliver strong thrust and clean, wide visuals. Redfox A3 45A AIO ensures fast response and high efficiency. GPS included for reliable RTH in any environment.
Feature
1. Compatible with Analog / O3 / O4 Pro, switch freely between scenarios to meet varied creative needs.
2. DC frame design delivers clean visuals and heightened flight immersion.
3. 1804 3450KV motors + 45A AIO ESC ensure fast response for all flight maneuvers.
4. Integrated side-plate structure combines aerodynamics and durability, protecting core components for impact-resistant flights.
5. GPS standard across all models enables confident flying and RTH, handling complex environments with ease.
Model: OasisFly35 DC O4 Pro Version
Wheelbase: 175mm
Arm Thickness: 3.5mm
Bottom Plate: 1.5mm
Mid Plate: 2.5mm
Top Plate: 2.0 mm
Motor Mounting Pattern: 9*9mm / 12*12mm
VTX: DJI O4 Pro
Motor: 1804 3450KV
FC: RedFox A3 45A AIO
ESC Firmware: BLHeli_32
MCU： STM32F722
IMU：ICM42688-P
Propeller: HQ 3.5*3.5*3
Receiver: ELRS/PNP
GPS: SUB-M10
Recommended Battery: 4S 530mAh
Power Connector: XT30
Body Weight: 194g
Takeoff Weight: 245g (with 4S 530mAh battery)
Max Flight Time: 5min 20s
FC Firmware & Betaflight_4.5.2-SUB250REDFOXF722AIO
